Transfer a Docker Image from Mac to Pi

TLDR

It didn’t work out. Don’t bother repeating it. It seems that with this way, the image is not of the correct architecture!

Aim

I’d like to transfer Docker images without depending on an external repository like Docker Hub.

Protocol

Check the images:

docker images

Save the image to a tar file:

docker save -o myImage.tar rolfsuter/testmultiarch:latest

Copy the tar file to the Pi:

scp myImage.tar pi@[IP]:myImage.tar

Connect to the Pi:

ssh pi@[IP]

List the current Docker images on the Pi:

sudo docker images

Load the image from the tar file:

sudo docker load -i myImage.tar

Check the image. Run:

sudo docker run --rm rolfsuter/testmultiarch:latest uname

Response:

standard_init_linux.go:211: exec user process caused "exec format error"

References

Exploring F# with .NET and Docker on Raspberry Pi

Recently, I got a Raspberry Pi 3 Model B. Now, I’d like to figure out, if I can run an F# server in a Docker container on it. I am aware that the currently installed Raspberry Pi OS is actually a 32-bit OS while the processor of my Pi has an 64-bit architecture. This has an impact if I’d like to install .NET directly on the OS. Since I intend to use Docker, I’ll sort that out later and just try to get it going.

Proof of principle

Try to run a container with .NET installed:

sudo docker run -it microsoft/dotnet:latest

Since I managed to spin up a .NET container, the next step is to create an F# console application and run it:

mkdir test
cd test
dotnet new console -lang "F#"
dotnet run

I am also able to run the dll file directy:

dotnet bin/Debug/netcoreapp2.1/test.dll

To exit the container and keep it running, I press [ctrl] + [p] followed by [ctrl] + [q].

Bind mount a host directory

First I create in the current directory a folder hostFolder containing a subfolder on the host system. I’ll mount hostFolder into the container below.

mkdir hostFolder
mkdir hostFolder/subfolder

Then I create a container from the image microsoft/dotnet:latest. Using the -v flag, I mount the hostFolder into the /targetFolder in the container. Note that the directory targetFolder is created in the root directory (/). The term "${PWD}"/hostFolder determines the path of the hostFolder to mount with ${PWD} being the current working directory. The part after the colon : with the path /targetFolder defines the mount point in the container. The -w flag determines the working directory in the container. Thus, I get directly into the /targetFolder/subFolder directory in the container.

sudo docker run -it \
       -v "${PWD}"/hostFolder:/targetFolder \
       -w /targetFolder/subfolder \
       microsoft/dotnet:latest

For testing I create a test file within the subfolder on the container and see it on the host system.

sudo docker run -it -v "${PWD}"/Source/Repos/Lab/TestApp:/TestApp  -w /TestApp microsoft/dotnet:latest

Add a Dockerfile

A Dockerfile describes how Docker creates an image and runs it. However, I’d like to develop on my Mac and try to setup the docker image there. Thus, I’ll setup a SAFE stack app on my Mac in another post.

References

Working with Docker

Here are some notes about working with Docker. On my Raspberry Pi I need to run all commands as sudo.

First of all, do not confuse the different terms. An image is like a blueprint that serves to generate containers. The containers are then the actual instance that you can start or stop.

List images

docker images

List containers

  • Show the running containers:
docker ps
  • Show all containers:
docker ps -a
  • Use the container command. I don’t know it it differs from the ps command above. The output seems to be the same.
docker container ls

Start a container

  • List the available containers (see above)
  • Get the container ID to start
  • Run
docker start [Container ID]

e.g.

docker start 725dc751823b

Exit a container without stopping it

If started a container with the docker run options -i and -t, you can detach from it and leave it running:

  • Press [Ctrl] + [p] followed by [Ctrl] + [q]

Connect/attach to a running container

docker attach [Container ID]

References

Run Pi-hole in a Docker container on a Raspberry Pi

I set up Pi-hole on a Raspberry Pi already a while ago and it is running fine. These are my notes that I took during installation. Unfortunately, the lack some details…

scp docker_run.sh pi@[IP]:docker_run.sh
  • Connect with SSH to the Raspberry Pi
  • run the script
sudo sh docker_run.sh

The script starts well but then encounters an issue after running the container:

Starting up pihole container docker_run.sh: 19: [: healthy: unexpected operator
.docker_run.sh: 19: [: healthy: unexpected operator
.docker_run.sh: 19: [: healthy: unexpected operator
.docker_run.sh: 19: [: healthy: unexpected operator

List all Docker containers

sudo docker container ls

Check the container

sudo docker inspect [Container ID]

Set the password for Pi-hole

Search the log file for the password

sudo docker logs pihole

References
